Getting Your Ink to Dry Fast: The 560mm Halogen Lamp
If you’re running high-speed ink curing lines, you know the struggle. You need the ink dry now, but you can’t just blast the whole project with heat or you’ll ruin the material. That’s exactly why we built this 560mm halogen lamp. It pumps out 1500W at 400V, which basically means it hits the surface with a massive burst of shortwave infrared energy. Here’s the thing about the power. We went with 400V because standard 230V lamps just can’t hit the same heat levels without drawing way too much current. At 1500W, you get that “flash” effect. It evaporates the solvents right off the top without cooking the substrate underneath. You get the surface dry and crisp, while the rest of your material stays safe. And the speed? It’s instant. Unlike those old-school element heaters that take forever to warm up, these lamps are at full blast the second you flip the switch. We used a quartz tube and a halogen cycle to keep things clean. Without that cycle, the tungsten filament would just evaporate and smudge the glass, killing your light output. With it, the tube stays clear and the heat stays consistent for a long time. Now, if you’re looking to swap these into your current drying tunnels, they should slide right in. The 560mm length is a standard fit. But a quick tip:**check your reflectors.**If they’re dull or dirty, you’re basically throwing half your money (and energy) into the air. Give them a polish. One last thing—be careful with the heat. Packing 1500W into a small 560mm space gets incredibly hot. If your cooling fans are old or underpowered, you’re asking for trouble. You don’t want to melt your sockets or warp your housing. Just keep the airflow moving and you’ll be golden.
